Plates, bowls, trays, cutlery, stainless steel containers, GN pans, baking trays.
We are a professional commercial dishwasher manufacturer with a 6,000 m² factory, equipped with laser cutting machines, CNC bending machines, punching machines and laser welding machines. With strict quality control and experienced technicians, each machine is fully tested before delivery to ensure stable performance and long service life. Our engineering team continuously improves product design based on market demand. We provide flexible OEM and ODM services, including logo, structure and function customization. Our products are exported worldwide, serving distributors and project partners with reliable after-sales support.
We cooperate with experienced logistics partners to ensure stable transportation and smooth international delivery.
|
Model |
CL-7200YH |
CL-7200YH |
|
External Dimention (mm) |
7200*900*1970 |
7200*900*1970 |
|
Passing width(mm) |
620 |
620 |
|
Max washing height(mm) |
450 |
450 |
|
Max washing capacity(R/H) |
3000-4800 |
3000-4800 |
|
Water consumptionl liter(hour) |
300-350 |
300-350 |
|
Washing Tank volum(L) |
105+105 |
105+105 |
|
Booster Volume(L) |
11 |
11 |
|
Washing Temperature(*c) |
50-60 |
50-60 |
|
Rinse Temperature(°C ) |
80-90 |
80-90 |
|
Water Supply Pressure(Mpa) |
0.25-0.4 |
0.25-0.4 |
|
Water inlet diameter(in) |
½/20 |
½/20 |
|
Heating Mode |
Electric heating |
Steam heating |
|
Steam consumption(kg/h) |
/ |
65 |
|
Steam inlet pressure(Mpa) |
/ |
0.3-0.4 |
|
Steam inlet pipe diameter(in) |
/ |
G1"(1寸) |
|
Steam outlet pipe diameter(in) |
/ |
G3/4"(6分) |
|
Tank heating(kw) |
9 |
/ |
|
Booster heating(kW) |
26 |
/ |
|
Wash pump(kw) |
2.2+2.2 |
2.2+2.2 |
|
Total load(kw) |
83/86/89 |
33/42/44 |
|
Power requirment |
380V/50HZ/3NPE |
380V/50HZ/3NPE |
